Offering keypad PIN (Password), Smart Card and biometric Fingerprint Authentication options, the ACTAtek combination unit is used in both security (access control) and workforce management applications.

  • Embedded Web server for easy access via any browser
  • Encrypted network communication
  • Optional built-in CMOS/Video camera for Video Surveillance( system diagram)

The ACTAtek Combination Unit is one of the most popular choices for both access control (AC) and time & attendance (TA) applications. Ease-of-use, no software installation and easy network connection create a simple yet sophisticated enterprise-wide platform for many system level software applications.

By combining biometric fingerprint, RFID smartcard, PIN (keypad) and a CMOS/Video camera, IT manager, security director and HR are able to select multiple way for users to authenticate for both AC and TA.  A choice of smartcard readers is offered, enabling legacy card systems to be part of the new platform solution.

This unit is built for heavy use. An IP65  product operating over the extended temperature range, this unit will continue to deliver even in extreme weather conditions.

  • Embedded software, no software installation necessary.
  • State of the art embedded, encrypted Linux web server technology. Control, configure & administrate via web browser
  • SSL encrypted communication between units & browser
  • Real time system update & configuration
  • 500DPI optical scanner
  • Auto-match support up to 10,000 users (1:N)
  • Operates in Standalone or Network modes(Access Manager)
  • Robust and scalable (thousands of users on global basis) for enterprise-wide deployment
  • IP 65 rated, weather & impact resistant casing (fluid ingress, dust, salt, fog protection)
  • Built-in CMOS/Video camera forVideo Surveillance(optional)
  • Up to 500 photos (FIFO internal storage)
  • API support for easy interface to most software applications
  • 1,000, 3,000 , 5,000 ,10,000, 15,000 or 20,000 users
  • Up to 75,000 event logs
  • Five Modes of authentication
    1. Fingerprint only
    2. Smart Card only or Barcode only
    3. Smart Card + Fingerprint or Barcode + Fingerprint
    4. ID + Fingerprint, and
    5. ID + PIN.
  • Multi-lingual interface (LCD & Web)
  • Wiegand 26-bit output (Optional –External I/O board)

Scanner Features:

  • Fingerprint image resolution:  500DPI
  • False Rejection Rate (FRR): 0.01%
  • False Acceptance Rate (FAR): 0.0001%
  • Allowed fingerprint rotation: +/- 15 Degrees
  • Matching speed: 0.05Sec
  • Scanning speed:  < 1 sec

Smartcard Reader Options:

Description Reading Distance
 MIFARE®  MIFARE® :  ISO 14443A  3 – 3.5 cm
 HID  iClass
ProxCard II
ProxKey II
ProxCard Plus
Smart DuoProx II
Smart ISOProx II
DuoProx II
ISOProx II
MicroProx Tag(Supports formats of 26, 34, 35 & 37 bits)		  3 – 3.5 cm
8 – 10 cm
3 – 5 cm
6 – 8 cm
6 – 8 cm
6 – 8 cm
6 – 8 cm
6 – 8 cm
3 – 5 cm
 EM  EM4100 Compatible  6 – 8 cm
 Felica  SONY FeliCa®  2 cm
 CEPAS  CEPAS, Singapore Standard  <1 cm
ACTA series IoT devices – Options for additional functionality
External I/O board: can be installed/hidden inside the secure premises ensuring no direct access to door strike connections.
WiFi Adaptor: To create a wireless network connection in WLAN environment
Power Over Ethernet (PoE) splitter: to provide the unit with a 12V supply from Ethernet that has PoE capability.
Mobile Battery Kit: IP67 case and battery to power one ACTAtek in mobile applications.
3G GSM / WiFi Gateway Modem. To provide cellular data connection in remote locations. Also offers a WiFi gateway.
UPS: a 12VDC/3A battery supply to maintain AC and TA integrity during power outages.
